BOTTICELLI



 ELECTROMECHANICAL OPERATOR -TECHNICAL FEATURES
Control Panel Venere D(incorporated)
Reversible/Irreversible Irreversible
Power Supply
230V ~ +-10%, 50Hz single phase
Absorbed Power 236W
Force 600N
Opening or Closing Time 28s
Impact Reaction Electronic torque limiter intergrated in the control panel
Type Of Limit Switches Electronic with encoder
Manual Release Unlocking with rope
Operating Cycle Very intensive use
Environmental Conditions from -15o C to +60o C
Degree of Protection IPX0
Operator Weight 50N (~5kg)
