Technical Specifications |
|
| Power supply
|
120 V AC -10 % to 240 V AC +10 %; 50/60 Hz
|
| Power consumption
|
max. 250 W
|
| Recommended max.
|
door weight 100 kg/door leaf
|
| Open and closing speed variable
|
variable up to 1.4 m/s
|
| Hold-open time
|
0 – 60 s
|
| Ambient temperature
|
-20°C to +50°C
|
| Relative humidity (non-condensing)
|
5% to 85%
|
|
Standard equipment |
|
| Operator including
- Drive unit with transmission - Electronic control unit with plug-in connections and power supply - Traffic-controlled opening width - Synchronizing of two operators |
|
| Door leaves made from aluminium profiles
|
|
| Outer walls made from aluminium profiles
|
|
| Glass: 4+4 mm clear laminated (Other types available)
|
|
| Presence detection safety sensor placed vertically and flush mounted above the entrance
|
|
|
Accessories and Options |
|
| Surface treatment:
- Clear anodized aluminium (other anodizing optional) - Paint finished in colour RAL (paint finishes according to RAL chart optional) |
|
| Door adaptor for doors made by others
|
|
| Programme selectors
|
|
| Electronic emergency opening or closing unit
|
|
| Mechanical emergency opening unit
|
|
| Emergency button
|
|
| ASSA ABLOY approach and presence sensors
|
|
| Electromechanical locking device
|
|
| Interlocking between two operators
|
|
| Key switch
|
|
| Mechanical lock (on door leaves)
|
|
| Ceiling (internal door operators only)
|
|
| Dust protection roof
|
|
| Water resisting cover
|
|
| Spotlights
|
|
