UNITURN

The UniTurn revolving door creates an inviting and spacious entrance by utilizing a perimeter drive that eliminates the need for a bulky centre shaft. This creates a larger door compartment area capable of accommodating shopping and luggage carts, wheelchairs and large numbers of users with ease. The UniTurn provides excellent separation of the interior and exterior environments, reducing heating and/or cooling losses. It also features two enclosed display cases within the rotating door leaves that can be used for informational promotions or advertising. The UniTurn is designed for placement directly on the finished floor surface with no special foundations required. Optionally, it can be fitted with a key-activated centre sliding door that allows it to be used as a fully automated sliding door entrance for additional ventilation and greater access to the building.


TECHNICAL SPECIFICATIONS

 Standard Equipment
- Curved glass: 4+4 mm clear laminated
- Flat glass : 3+3 mm clear laminated
- Other type of glasses available
- Door sections of aluminium profiles
- Center door leaves with break out function
- Ceiling of white laminated panels
- Spotlights or Downlights
- Dust protection roof
- CDC control unit build in behind the fascia beside the inside entrance
- Build in activators
 Optional
Finishes:  - Power-coated finish (RAL colours)
               - Anodizing, clear or bronze
               - Stainless steel cladding
 Technical Specifications
- Power supply : 100 – 240 V, 50 – 60 Hz
- Mains fuse 10 A
- Power consumption
    - Drive unit        600 W
    - Spotlight         500 W
    - Downlights     200W
