TECHNICAL SPECIFICATIONS |
|
| Model
|
ORO
|
| Type
|
Hydraulic
|
| Control Panel
|
ALGOR AC A
|
| Operator
|
Irreversible
|
| Power Supply
|
230V~+-10%, 50Hz single phase
|
| Leaf Weight
|
up to 1800N (~180kg)
|
| Leaf Length
|
up to 1.8m
|
| Absorbed Power
|
240W
|
| Thermal Protection
|
Intergrated
|
| Rod Working Stroke
|
250mm
|
| Rod Speed
|
12mm/s
|
| Opening / Closing Speed
|
20s
|
| Impact Reaction
|
Hydraulic clutch
|
| Type of Lock
|
Hydraulic on closing
|
| Manual Release
|
Release key
|
| Operating Cycle
|
Semi intensive use
|
| Environmental Conditions
|
From -10C to +60C
|
| Degree of Protection
|
IP55
|
| Operator Weight
|
53N(~5,3kg)
|
