TECHNICAL SPECIFICATIONS |
|
| Door Panels
|
Robust steel reinforcement (min. 5mm) for hinges and mountings and a hand-wearing outer covering increases durability
|
| Up-Value
|
0.77-0.93
|
| Wind Load
|
0.7 kPa
|
| Sealing System
|
T-value of 0.58-1.03m3/m2/H
|
| Adjustable Hinges
|
KGJQ (=standard hinge) normally used together with a steel plate doorsill 100x10mm that is fitted to the floor. Each time the door moves the steel doorsill is swept off; proving a flat and clean sealing surface. KGJQ is adjustable vertically
|
| Locking
|
Q-door is operated and locked, on the inside using a padlock on an external cremone bolt.
|
| Windows
|
Q-door's windows are made using extuded aluminum frames with an open thermal bridge with genuine double glazed insulation glass D4-12 or trible glazed insulation glass T4-9
|
