TECHNICAL SPECIFICATIONS |
|
| Reversible/Irreversible Operator
|
Irreversible
|
| Power Supply
|
230/400V ~ +- 10%, 50Hz three-phase
|
| Absorbed Power
|
1500W
|
| Thermal Protection
|
Overload cutout inside the control panel
|
| Max Leaf Weight
|
35000N (3500kg)
|
| Leaf Speed
|
10m/min
|
| Output Revolution
|
30rpm
|
| Pinion Pitch
|
6 (18 teeth)
|
| Type of Limit Switches
|
Electromechanical
|
| Manual Release
|
Mechanical release with knob
|
| Control Panel
|
SIRIO TEL
|
| Operating Cycle
|
Very intensive use
|
| Environmental Conditions
|
from -15 to +60C
|
| Degree of Protection
|
IP54
|
| Actuator Weight
|
850N (~85kg)
|
