TECHNICAL SPECIFICATIONS |
|
| Model
|
TSP
|
| Frame
|
Extrusion white lacquered aluminium, beautified with invisible screws
|
| Door Blade
|
External and internal basin in lacquered sheet, P.V.V or Aist 304 stainless steel, plastic laminated in phenolic resin, joined by a P.V.C profile
|
| Thickness
|
40mm
|
| Insulation
|
High pressure injected polyurethane from 50kg/m3 (bayer), free of CDC and HCFC
|
| Optional
|
Sky-holes: 400x600mm in metacrylath, joined with a grey and compact EPDM sealing 412x594mm laminated glasses, leanness with the door
Rounded: 400mm diam. With stainless steel frame Lock and key Automatic unit Stainless steel frame Stainless steel pullers Stainless steel grips |
